Product Highlights • Designed for casement windows • Standard duty recommended for a maximum vent weight of 82 lbs. 4 bar hinges are certified to AAMA 904.1 • 4 bar hinges are adaptable to both casement and projected window • Non-handed and made of durable stainless steel • 222/333 Series Hinges can produce a 90 degree window opening allowing an average-sized person • 4 bar egress hinges allow outside vents to be washed from the inside • 4 bar hinges have been designed to be used primarily on vents with a lip on the outside edge • By design, our 4 bar hinges are engineered to project the vent out as it pivots to avoid interference
Specifications
PART # HINGE POCKET HEIGHT LENGTH 34.10.00.101.1 1/2" 8" 34.11.00.101.1 1/2" 10" 34.12.00.101.1 1/2" 12" 34.13.00.101.1 1/2" 14" 34.14.00.101.1 1/2" 16"
